DT Bucket Elevator

DT Bucket Elevator

Application:DT hoists are widely used in port terminals, processing plants, grain depots, grain and oil processing plants and flour mills

Capacity:1t-100t/h

DESCRIPTION

Bucket elevator is vertical or inclined more than 70 degrees of bulk material conveying equipment, there are also special powder lifting conveying model. DT hoists are widely used in port terminals, processing plants, grain depots, grain and oil processing plants and flour mills. The special mould is used to press the multi-layer cylinder with bite edge, which has high strength and good sealing performance; The surface of the driving head wheel is coated with glue to reduce slipping, and it is also equipped with a reinforced tension device.

FEATURE

  • It is widely used

    DT Elevators are widely used in port terminals, processing plants, grain depots, grain and oil processing plants and flour mills.

  • Highly professional

    The special mould is used to press the cylinder with multi-layer bite edge, which has high strength and good sealing performance.

  • Advanced technology

    The surface of the driving head wheel is coated with glue to reduce slipping, and it is also equipped with a reinforced tension device.

  • Low energy consumption

    The whole set of equipment has the characteristics of strong specificity, reasonable layout, low power consumption and low cost.

EQUIPMENT DISPLAY

  • DT Bucket Elevator
  • DT Bucket Elevator
  • DT Bucket Elevator

TECHNICAL INDEX

type capacity(t/h) hoist speed(m/min) power(kw) dimension(mm)
DT-4 4 1.44 0.75-1.1 1000×450×4100
DT-6 6 1.44 1.5 1000×450×5100
DT-10 10 1.44 2.2 1000×450×5100
